Gobosource Home » Catalog » Virtual Signs and Lines » Virtual Sign Bundles » Virtual Sign 1’ to 3’ Industrial Environments (C20PCE)
[ES-C20PCE-SB]

Virtual Sign 1’ to 3’ Industrial Environments (C20PCE)


$357.00
Select a Sign
Ambient Brightness
Desired Image Size or Size Range
Mounting Distance or Range
Quantity
Virtual Sign Bundle, 1' - 3' Sign Size, ES-C20PCE - Save Up To $129! Up to 3ft size in Bright Environments


Description
Features
Specifications
Photometrics
Resources
This bundle consists of an ECO Spot C20PCE LED Gobo Projector configured with a STOP sign.

The C20PCE is the most compact version of our PCE-Series projectors. It is designed for industrial, dusty or wet environments. It has no moving parts such as fans or motors.

Please select the sign you would like, the brightness level, your required projection size, and mounting distance above. Based on these values, we will select the most effective projection lens combination for you. If you are flexible with the mounting distance and required image size, please enter a range, it will help us to optimize your configuration.

We will always contact you to clarify any possible issues and send you an order confirmation before proceeding with your order.
  • Extremely compact, yet strong, crisp projection.
  • Passive Cooling, no fans or motors.
  • Threaded gobo holder for quick and easy gobo replacement, hand gobo rotation for easy gobo centering.
  • Interchangeable projection lenses make it easily adaptable to a wide range of applications.
  • 40,000 hours LED life - never exchange a bulb over the life of the projector.
  • The Power Supply (driver) is detached, to allow for the smallest possible footprint.
  • Multi Voltage 100-240/277V 50/60Hz.
  • Full aluminum housing.
    Order Code:ES-C20PC
    Power Supply:100-240/277V, 50-60Hz, 25W (driver is detached from projector housing)
    Ambient Temp. Range:-22°F to 122°F (-30°C to 50°C)

  • Optical
    • Lamp:20W LED, 30,000h rated life
    Projection Lens Included:yes, choose from options below
    Available Lenses:Narrow: f=140mm/10°, Semi-Narrow: f=100mm/15°, Medium: f=70mm/20°, Wide: f=56mm/25°, Ultra-Wide: f-28mm/45° (Max ID with this lens is 23mm)
    Gobo Size:E-Size - Outer Diameter: 37.5mm, Image Diameter: 25mm, max. Thickness: 3.3mm
    Gobo Types:Glass, Metal, Film (film life 2 to 5 days)
    Effective Luminous Flux:1,000lm (1800lm nominal)
    Color Temperature (Kelvin):7,000k +/-500k

  • Lens Range
    • Bright - up to 30 ft
    Dim - up to 60 ft
    Dark - 140 ft

  • Dimensions
    • Base2.75” x 3”
    Total Length:8-10” (depending on projection lens)
    Total Height:5.5” (incl. yoke)
    Weight:2.4lbs
    Projector Box:14” x 8” x 5”, 4.1 lbs
    Master Carton:16.5” x 14.5” x 11”, 8.5 lbs

  • Package Contents
    • Power Supply (Driver)
    Test Gobo
    User Manual

Projection Chart

User Manual
Spec Sheet
Find the Right Projector - Click Here
Product Warranty
