ECO Pattern Wayfinding Projector - Animated Arrows

The WFA-G is designed for industrial, dusty or wet environments.

• IP65 rated for wet, dusty environments
• Passive Cooling - no fans or motors.
• Ideal for dusty and wet industrial environments.
• Long service intervals.
• Wide line voltage range.
• 35,000 hours bulb life (L70).
• Quality optical system with interchangeable Lenses.
• Full Aluminum Housing

• Projector

Order Code:	ES-WFA-G
Power Supply:	100V - 240/277V, 50-60GHz, 80W
Ambient Temp. Range:	-22°F to 122°F (-30°C to 50°C)
Can be used in-/and outdoors	Exterior Version



• Optical

Lamp:	70W LED, 30,000h rated bulb life
Projection Lens Included:	yes, choose from options below
Available Lenses:	Semi-Narrow: f=210mm/13°, Medium: f=140mm/20°, Semi-Wide: f=115mm/25°, Wide: f=87mm/30°
Dimmable:	Yes, with trimmer



• Lens Range

Bright	- up to 50 ft
Dim	- up to 90 ft
Dark	- up to 180 ft (or more in very dark conditions)



• Dimensions

Total Length:	11 - 14” (incl. lens)
Height:	11.5”
Width:	8”
Weight:	11 lbs



• Package Contents

Power Cord

In-line Control Module

Test Gobo

Spare Gobo Retaining Ring

Integrated Gobo Mounts

User Manual
